Máy thổi bụi thò dài (long retractable) dùng để làm sạch tro/xỉ bám trên bề mặt trao đổi nhiệt vùng nhiệt độ cao của lò hơi như bộ quá nhiệt, tái nhiệt, bộ hâm nước, đỉnh lò và bộ sấy không khí kiểu ống; ống súng thò vào lò khi thổi và tự rút ra để tránh cháy ống.
Thông số kỹ thuật chính: (m) HXC-51 7.60 HXC-52 7.65～ 13.70 Hành trình (m): HXC-51 type, maximum 7.60 HXC-52 type 7.65-13.70 Môi chất thổi bụi: hơi nước hoặc khí nén (m/min) 0.9～3.5 Tốc độ tiến/lùi (m/min): 0.9~3.5 (r.p.m) 9～35 Tốc độ (r.p.m.): 9-35 (mm) 12～32 Đường kính vòi phun (mm): 12-32 (m) ～2 Bán kính thổi bụi (m):~2 360° Góc thổi bụi: 360 ° Y90S-4 B5 1.1KW~1400rpm Model động cơ: Y90S-4 B5 type 1.1KW~1400rpm 380V.3P.50Hz Nguồn điện động cơ: 380V.3P.50Hz HXC-51 360k+ (m)×116kg HXC-52 400k+ (m)×135kg Khối lượng gần đúng: HXC-51 360k+stroke (m) × 116kg HXC-52 400k+stroke (m) × 135kg Lưu ý: The stroke, forward and backward speed, rotational speed, number and diameter of nozzles, pressure and flow rate of the blowing medium, etc. of the soot blower are determined based on the calculation of boiler flue gas temperature, fuel and ash content, medium parameters, etc Main components 1. 1. Sports car and electric motor (reducer) 2. 2. Soot blower valve (lift valve) and counter flange 3. 3. Beam body 4. 4. Wall box (interface with boiler) 5. 5. Power cable 6. 6. Front bracket (supporting the soot blower) 7. 7. Inner tube 8. 8. Soot blower and nozzle 9. 9. Electrical box and travel control table (front and rear limit switches) 10. 10. Helical phase change mechanism (optional) 11. 11. Sealing device and sealing air and cleaning pipeline (positive pressure system) HXC-5 HXC-51 HXC-52 The HXC-5 series long retractable soot blowers are divided into two types based on their stroke: HXC-51 and HXC-52. Mainly used for blowing out ash and slagging on the heating surface of boilers. It can also be used to remove dust and slagging on slag traps, superheaters, reheaters, and economizers, as well as to remove dust from furnace tops and tubular air preheaters.
主要技术参数： Main technical parameters: 行程(m)： HXC-51型 最大7.60 HXC-52型 7.65～ 13.70 Stroke (m): HXC-51 type, maximum 7.60 HXC-52 type 7.65-13.70 吹灰介质：蒸汽或压缩空气 Soot blowing medium: steam or compressed air 进退速度(m/min)：0.9～3.5 Forward and backward speed (m/min): 0.9~3.5 转速(r.p.m)：9～35 Speed (r.p.m.): 9-35 喷嘴口径(mm)：12～32 Nozzle diameter (mm): 12-32 吹灰半径(m)：～2 Soot blowing radius (m):~2 吹灰角度：360° Soot blowing angle: 360 ° 电动机型号：Y90S-4 B5型 1.1KW~1400rpm Motor model: Y90S-4 B5 type 1.1KW~1400rpm 电动机电源：380V.3P.50Hz Motor power supply: 380V.3P.50Hz 近似重量：HXC-51 360k+行程(m)×116kg HXC-52 400k+行程(m)×135kg Approximate weight: HXC-51 360k+stroke (m) × 116kg HXC-52 400k+stroke (m) × 135kg 注明：吹灰器行程、进退速度、转速、喷嘴数量及口径、吹灰介质压力和流量等根据锅炉烟温、燃料及灰分、介质参数等计算确定 Note: The stroke, forward and backward speed, rotational speed, number and diameter of nozzles, pressure and flow rate of the blowing medium, etc. of the soot blower are determined based on the calculation of boiler flue gas temperature, fuel and ash content, medium parameters, etc
主要零部件 Main components 1.跑车与电动机（减速机） 1. Sports car and electric motor (reducer) 2.吹灰器阀门（提升阀）及反法兰 2. Soot blower valve (lift valve) and counter flange 3.梁体 3. Beam body 4.墙箱（与锅炉接口） 4. Wall box (interface with boiler) 5.动力电缆 5. Power cable 6.前托架（支撑吹灰枪） 6. Front bracket (supporting the soot blower) 7.内管 7. Inner tube 8.吹灰枪与喷头 8. Soot blower and nozzle 9.电气箱与行程控制表（前、后限位开关） 9. Electrical box and travel control table (front and rear limit switches) 10.螺旋线相位变化机构（选用） 10. Helical phase change mechanism (optional) 11.密封装置和密封空气及清污管道（正压系统） 11. Sealing device and sealing air and cleaning pipeline (positive pressure system)
HXC-5系列长伸缩式吹灰器根据行程分为HXC-51型和HXC-52型两种吹灰器。主要用于吹扫锅炉受热面上的积灰和结渣。也可用在清除捕渣管、过热器、再热器、省煤器上的积灰和结渣，还可用来清除炉顶和管式空气预热器的积灰。 The HXC-5 series long retractable soot blowers are divided into two types based on their stroke: HXC-51 and HXC-52. Mainly used for blowing out ash and slagging on the heating surface of boilers. It can also be used to remove dust and slagging on slag traps, superheaters, reheaters, and economizers, as well as to remove dust from furnace tops and tubular air preheaters.
Á Đông Group cung cấp thiết bị thổi bụi lò hơi Hubei Huaxin chính hãng tại Việt Nam — tư vấn, báo giá và hỗ trợ kỹ thuật.
